ÇATAL

550 505 22B CLEVIS Acting as a crucial pivot point, this CLEVIS connects a hydraulic SİLİNDİR rod to a moving part of the drill rig's positioning system. You will typically find it at the end of a boom or feed SİLİNDİR, where it allows for the angular movement necessary to position the drifter accurately for drilling. Its job is to transfer immense pushing and pulling forces reliably.

The integrity of this connection is directly tied to both operational safety and drilling performance. Wear in the CLEVIS PİM hole can cause unwanted play in the entire boom structure, leading to inaccurate collaring and increased stress on other pins and bushings. A sudden failure of a worn or cracked CLEVIS could result in an uncontrolled drop of the feed or boom, creating a serious hazard.

Rutin incelemeler sırasında ÇATAL BAĞLANTI (CLEVIS) parçasını, özellikle pim deliği çevresinde çatlak belirtilerine karşı kontrol edin. Ayrıca, delikte önemli bir aşınmaya işaret eden uzama veya 'oval' şekil arayın. Çalışma sırasında bağlantı mekanizmasından aşırı boşluk fark ederseniz veya takırtı sesleri duyarsanız, bu bileşen derhal incelenmelidir.
